Development Boards
Providing an enhanced portfolio of FPGA based development boards.
PicoSky™ Development Board IGLOO2/SmartFusion2
• Microsemi IGLOO2 M2GL050
• MRAM, SRAM, eMMC memories
• 2x LVDS, 2x SERDES, MIL-STD-1553B
• USB, UART, RS232, 2x CAN bus
• GPIO expansion headers
• MRAM, SRAM, eMMC memories
• 2x LVDS, 2x SERDES, MIL-STD-1553B
• USB, UART, RS232, 2x CAN bus
• GPIO expansion headers
PicoSky™ Development Board ProASIC3
• Microsemi ProASIC3 A3PE3000
• SRAM, MRAM, PSRAM memories
• 2x SpaceWire, MIL-STD-1553B
• 2x CAN, 2x RS232, 8x RS422
• GPIO expansion headers
• SRAM, MRAM, PSRAM memories
• 2x SpaceWire, MIL-STD-1553B
• 2x CAN, 2x RS232, 8x RS422
• GPIO expansion headers
PicoSky cpciSDR 1×1 SKY-9202
• 3U CompactPCI® SDR Card
• RF Agile 1x1 Transceiver
• Frequency band: 70MHz to 6GHz
• Xilinx Artix®-7 FPGA for SDR
• Redundant SpaceWire and CAN bus
• RF Agile 1x1 Transceiver
• Frequency band: 70MHz to 6GHz
• Xilinx Artix®-7 FPGA for SDR
• Redundant SpaceWire and CAN bus
PicoSky Evaluation Board SKY-9213
• PicoSkyFT SoC on Microsemi IGLOO2
• MRAM and eMMC memories
• PicoSkyLINK integrated
• USB, UART, SPI/I2C, redundant CAN
• PC/104-size form factor
• MRAM and eMMC memories
• PicoSkyLINK integrated
• USB, UART, SPI/I2C, redundant CAN
• PC/104-size form factor
